We are going to divided into three steps.
1) Locate the start and finish lines.

  • Put a photocell and its reflector, one in front of another. Repeat this for the start and finish line.
  • [Only for Cronox 2.0] Extend the wire extension between both of them.

2) Connect each photocell and wire extension into its respective ports (Start – A and Finish – B) of the Cronox Timing System box.

Cronox 3.0 Wiring Scheme

3) Download the official app and connect by bluetooth.
